【 AP1200 - AC1200 Outdoor 1.0 】
-3 Year Local Warranty
A pole/wall-mounted WiFi AP with IP65 casing and PoE, ideal for park, farm, and parking lot environments.
KEY FEATURES:
• IP65, -40~65°C (-40~149°F), 4kV Surge
• 4-Stream Dual-Band Wi-Fi 5
• 867 Mbps + 300 Mbps Wi-Fi 1
• 1× Fast Ethernet Port
• 24V Passive PoE
• 30 Connected Devices 2
• Router/AP/RE/WISP/Client Modes
WHAT'S IN BOX:
• AP1200 Outdoor
• Detachable Antennas
• PoE Adapter
• Power Cord
• Mounting Kit
• Ethernet Cable
• Installation Guide
|
Features: • Model Version: AP1200 Outdoor 1.0 • CPU Details: 580 MHZ Single-Core CPU Memory/Storage • Flash/ROM: 8 MB (64 Mbit ) NOR • DDR/RAM: 64 MB (512 Mbit) DDR2 Wireless • 5 GHz Wi-Fi Speed: 867Mbps • 2.4 GHz Wi-Fi Speed: 300Mbps • 5 GHz Wi-Fi Streams: 2T2R (2×2 MIMO) • 2.4 GHz Wi-Fi Streams: 2T2R (2×2 MIMO) • Wall Performance: NA • Wi-Fi Antennas: 2× Detachable • FEM or PA/LNA: 5 GHz: 2× Internal, 2.4 GHz: 2× Internal • Detachable Wi-Fi Antennas Connector: RP-SMA Female • Beamforming: True • Range Performance Max: 170 m (558 ft) Park: 150 m (492 ft) Street: 50 m (164 ft) Woods: 30 m (98 ft) Interfaces • 10/100 Mbps RJ45 Ports: 1 • Ethernet Notes: Accepts PoE powering • LED: 5 GHz Wi-Fi; 2.4 GHz Wi-Fi; LAN; Internet; System • Physical Buttons: WPS Button, Reset Button • Power Input: PoE via Ethernet Port Power • Power Methods: Passive PoE • Passive PoE Input: 24V • Power Adapter: Input: 100 ~ 240 V, 50/60 Hz AC, Output: 24V Passive PoE • Max Power Consumption (W): 12 W • Idle Power Consumption (W): 2.5 W Reliability EMC： • ESD: Contact: 4kV; Air: 8kV • IEC/EN 61000-4-5, Level 4 Surge: Power: DM 2kV, CM 4kV; RJ45: CM 4kV Environment： • Operating Temperature: -20 ℃ ~ 60 ℃ (-4 ℉ ~140 ℉) • Extend Operating Temperature with Industrial Grade SIM Card: -40 ℃ ~ 65 ℃ (-40 ℉ ~ 149 ℉) • Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) • Operating Humidity: 0% ~ 100% non-condensing • Storage Humidity: 5% ~ 90% non-condensing • Ingress Protection Rating: IP65 When devices is installed vertically Certifications: FCC, CE Mechanical • Installation: Wall-mount， ’Pole-mount Dimension: • Device Body: 240×100×53.7 mm • Each Antenna: 197.5×21.6×15.5 mm • Product Weight: 415 g |
